SGC Access Controls
Driveway Gate Entry & Exit Controls and Parts
Residential and Commercial Gate Access Controls.
Our Gate Products
email Us for info on any of the above products
See DOWNLOADS for more information on our products
MiniLoop Single Channel Loop Detector
- Height: 3/4 in
- Width: 1-7/16 in
- Depth: 2-3/16 in (including connector)
- Selectable Settings Sensitivity, Frequency, Boost, Presence, Pulse time
- See DOWNLOADS for more information
PB800 Pushbutton-D
- Black Powder Coated Steel Enclosure
- Stainless Steel Faceplate
- Delay version: 5s, 10s timer delay
- Waterproof
- Free Exit Push Button with Lockout On/Off
- See DOWNLOADS for more information
KP900 Touch Keypad
Embedded Touch Keypad
- Black Powder Coated Enclosure
- Stainless Steel Faceplate
- One relay,1000 users (990 common users+10 visitor users)
- Touch keypad PIN length:4~6 digits
- Tri-color LED display>Backlit keypad, can set automatic OFF after 20 seconds
- Wiegand 26 bits output> Wiegand 26/34 bits input automatic identification
- See DOWNLOADS for more information
KP950 Keypad & Card
Embedded Keypad Access
- Black Powder Coated Steel Enclosure
- Stainless Steel Faceplate
- Waterproof, IP66
- One relay, 1000 users (990 Normal Users + 10 Visitor Users)
- 3 access modes: Card, PIN, Card + PIN
- Card type: 125KHz EM card
- PIN length: 4~6 digits
- Anti-tamper alarm
- Wiegand 26 bits output
- Wiegand 26/34 bits input automatic identification
- See DOWNLOADS for more information
Exit1000 No Touch
No Touch Exit Button
- Black Powder Coated Steel Enclosure
- Stainless Steel Faceplate
- Output contact: NO/NC/COM
- Sensor distance: 3~15cm (Adjustable)
- Blue LED indicator: standby
- Green LED indicator: active
- Waterproof
- 5s, 10s timer delay or Toggle Mode
- Private Labeling Available
- See DOWNLOADS for more information
CR975 Card Reader
Embedded RFID Access
- Black Powder Coated Steel Enclosure
- Stainless Steel Faceplate
- Waterproof
- Card type: 125KHz EM card or 13.56MHz Mifare card optional
- Pulse mode, toggle mode
- Built in LDR for anti tamper
- Card block enrollment
- Wiegand 26 bits output
- Wiegand 26/34 bits input automatic identification
- Private Labeling Available
- See DOWNLOADS for more information
RR1050
- User capacity: 100 fingerprints and 3000 cards
- Card type: 125KHz EM card
- One programmable relay operation
- Latch mode to hold door or gate open
- Tri-color LED status display
- Special Order Item
- See DOWNLOADS for more information
GateGuard 1100
- HD 2.0 MP camera, 120° wide angle view.
- Black Powder Coated Steel Enclosure
- Stainless Steel Faceplate
- Tuya App- Wifi & Bluetooth pairing.
- Wireless Wifi or RJ45 CAT5 cable connection. Answer and unlock the door from mobile phone, both Android and iPhone.
- Live video, snapshot, video record, motion detection.
- LED lights for night vision
- Waterproof
- Card and Key Fobs Reader
- Private Labeling Available
- More Information
Gate Edge Transmitters & Receiver
A gate safety edge kit is a crucial safety component for automatic gates that detects obstructions and signals the gate operator to stop or reverse motion, helping prevent accidents.
SGC Model S-1003 Gate Safety Edge Kit Transmitter and Receiver wireless setups, a battery-powered transmitter sends a signal from the edge to a receiver connected to the main gate control panel, eliminating the need for extensive wiring
Gate Operators and Controls
Swing Gate Operators
RSW-2500 Dual Residential Column or Post Mount
The RS-2500 swing gate operator is ideal for large pillars and columns. It can handle a gate weighing up to 800lbs and 11ft. in length. Battery backup is standard along with its emergency release lever. Comes with (2) One Button Remotes, and (1) Safety Reflective Photo Beam.
Optional Post Mount Kit available.
MAX-3500 Dual Residential & Light Commercial
This heavy-duty swing gate operator is designed to provide exceptional power and reliability for large and heavy gates. Its high-torque motor delivers strong operating force to withstand high wind loads, making it ideal for solid-panel gates exposed to harsh weather conditions. The operator is engineered for frequent use without overheating or shutting down. Comes with (2) One Button Remotes, and (1) Safety Reflective Photo Beam.
PRO-4500 Swing Gate Operator
The Pro4500 swing gate operator for single family residences and residential complexes up to 15 units. Designed for super-quiet operation, it can handle up to 250 cycles per day* with gates weighing up to 400 lbs. and up to 16 feet in length. Unlike other systems, the PRO4500 is designed with a “non-scissor action” swing arm to greatly reduce the risk of injury. The system features a DC motor with a 12-volt, 7-amp hour battery for dependable operation.
More Information
Operator Accessories
Remotes, Receivers, Goosenecks and Parts
Remote Controls
One Button Remotes
Two Button Remotes
Sun Visor Clips
Long Range Remotes
Radio Receivers
Antenna Kits
Radio Receivers
Radio 350 Simple 2 channel momentary open relay hold 200 remotes
Radio 360 Has Jumper to change from Toggle, Latched or Momentary.
Radio 370 Wi-Fi connection
12V Control Board
Upgraded version of the Elite ROBO board.
NO Glass Fuses
Loop Connections
STOP Connection
Upgraded Relays
W1 is now a jumper connection
Premade Loops
The PVC-encased, Model 3660 Preformed Loop is designed for on-site installation prior to pouring concrete, asphalt or direct burial in dirt driveway. Unlike other products that call themselves "Preformed Loops" but are just coils of wire, our loop comes encased in PVC tubing which protects it from damage and "pre-forms" the loop into a 36-inch by 60-inch rectangle. Also, because it is self-contained, the 3660 Preformed Loop greatly reduces installation time.
Reflective Photo Beam
- Polarized sensor is immune to shiny objects: triggers only when correctly reflected light is detected
- Weatherproof (IP55)
- Anti-condensation housing
- 12-30V DC/AC 60Hz, 100mA
- Up to 33ft (10m) sensing range
- Round reflector, Diameter: 3-1/4" (82mm)
- Form C relay: 500mA@30VAC/VDC
- Beam status LED
- Compact size: 4-13/16"x2-3/8"x2-7/16" (122x60x62mm)
- N.C. Tamper switch: 500mA@30VAC/VDC
- Monitored Outputs:
- N.C.
Knox Style Fire Box
The Fire Box accepts Knox 3501 switches or fire padlocks that can be connected to the gate control box for easy opening of the gate by the fire department. Please note that each city has a different key lock, so you will need to enter your installation address to receive the correct lock. Please note that this box does not include a Knox key lock or padlock, which must be purchased separately from Knox.
Model 1：Fire box is used to hold a Knox Model 3501 switch (not included).
