CR-965/975 Card Access Reader

 The CR-975 Embedded RFID Access Control Reader offers a reliable and durable solution for secure access control. With a metal case and IP66 waterproof rating, it is designed to operate in challenging outdoor environments. It supports both 125KHz EM cards and 13.56MHz MF cards, and operates in temperatures from -40°C to 60°C. The reader features pulse and toggle modes, built-in LDR for anti-tampering, and supports Wiegand 26 bits output with automatic identification of Wiegand 26/34 bits input. This makes it an ideal choice for various access control applications, both indoors and outdoors.

• CR-975 Gooseneck
• CR-965 Flush Mount

•   Operating Voltage  12~24V DC
•  Metal Enclosure
•  Waterproof, conforms to IP66
• One relay, 2000 users, standalone
• Card type: 13.56Mhz
• Pulse mode, toggle mode
• Built in LDR for anti tamper
• Card block enrollment
• Wiegand 26 bits output
• Wiegand 26/34 bits input automatic identification

•  Frequency
  13.56 MHz
• Network
  4 g
• Operation System
  Android 11
• Protocol
  ISO 14443A
• Reading Distance
  0-3m
• Material
  Stainless Steel Faceplate / Steel Enclosure
• Wiring Connections

                    Relay output, exit button, wiegand (in & out)

• Relay / One  (NO, NC, Common)

                  Adjustable Relay Output Time 0-99 Seconds (5 seconds default)

                  Lock Output Load  2 Amp Maximum

• Product Name
  Embedded RFID Access
• User Capacity
  1000 Cards/PINS
• Card Type
  13.56MHz Mifare card
• Features
  Support pulse mode, toggle mode/Card block enrollment
• Wiegand Format
  Wiegand 26/34 bits input automatic identification
